Monitor the radiation dose to your body while performing radiography with the Universal Radiation Dose Meter. Universal Radiation Dose Meter achieves excellent results with NDT, oil and gas, and nuclear companies. It is also used in healthcare and life sciences, CBRNe and emergency services, and manufacturing, and in the environmental and waste management fields.
Universal Radiation Dose Meters are the easiest to use and understand in the personal radiation monitors category. The display system has radiation graphs and a simplified schematic where a human figure fills with color corresponding to the radiation dose of X-rays or gamma-rays received. Each Universal Radiation Dose Meter is equipped with weatherproof, shockproof, and drop-proof housings, a smooth, clean design, and intuitive software.
Identifies Beta, Gamma, and X radiation types.
Records total radiation doses and measures dose rates continuously.
Automatically chooses the measurement range.
Alarms can be customized by the user (with visual and audible signals).
Up to 10 data sets can be saved in the internal memory.
Designed for low power consumption with battery status and shut-off feature.
It is widely used in a variety of applications to measure and monitor exposure to ionizing radiation.
| Sensor Type | G-M Counter Tube |
| Measured Rays | Beta, Gamma, X |
| Radiation Dose Range | 0.05µSv/h to 50mSv/h |
| Accumulated Radiation Dose Value | 0.1µSv to 9999mSv |
| Accuracy | ≤25% |
| Energy Range | 80keV to 1.5MeV |
| Source | Cs-137 |
| Response Time | ≤10 seconds |
| Display | 2" color TFT LCD |
| Backlit Display | Yes |
| Adjustable Alarms | Yes (Audible/Visual Indicators) |
| Natural Environment Reading | 0 to 0.2µSv/h |
| Data Logging Capabilities | Yes |
| Real-Time Clock and Date Stamp | Yes |
| Internal Memory | Yes (up to 10 groups of data) |
| Power Supply | Built-in lithium battery (3.7V 1800mAh) |
| Battery Life | Approx. 20 days (Fully Charged) |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Operating Humidity Range | 20 to 80% |
| Storage Temperature | 14 to 122°F (-10 to 50°C) |
| Storage Humidity Range | 20 to 70% |
| Dimensions | 4.7 x 2.6 x 1" (120 x 65 x 25mm) |
| Weight | 130g |
